THE BEST FLEXIBILITY -> The only conveyor with NO BLIND SPOT !
- Telescope of 7.23 ft on the second section
- 360° rotating chute (system pattented) (Patent number # 06/02893)
- 3D extension, ideal for shuttered walls
- Chute extension to gain 3.3 ft
- 310° rotation around the truck
THE BEST INVESTMENT
- Several standard options (3D extension, dual rubber reception hopper, chute extension, semi-proportional controls … )
A DELIVERY QUALITY
- Wireless radio control for optimum versatility
- Hood with quick opening for cleaning
- Sliding system preventing concrete segregation and compatible with every kind of concrete plasticity
- Time saving (no stabilizers)
TECHNICAL FEATURES
- Conveying distance from 15.75 up to 43 ft
- Belt width 14.17 in
- Max. discharge rate 92 cu yds / h
- Rotation 310°
- Max. discharge height 18.05 ft
- Weight 4,000-4,400lbs
- Steel structure
- No stabilizer
ADDITIONAL OPTIONS
- High pressure washer
- Full-proportional controls for greater precison
